Static Phase Shifter

Static Phase Shifter
Static Phase Shifter
Product Code : 20
Product Description
Our company is an prominent exporter and manufacturer of Static Phase Shifter which is developed by our assiduous and highly skilled engineers using optimum quality material. The offered shifter can purchased by customer at an industrial leading price. Moreover, this shifter is widely acknowledged for following features:
  • Current as Reference phase and voltage vector -  phase shiftable.
  • Range of phase shift ( voltage phase) 0 - 360°.
  • Digital phase angle meter.
  • Analogue ammeter and Voltmeter.

Size:   315 x 475 x 330 mm         Weight:  22Kg.

Application:
  • Distance scheme protection testing
  • Directional relay testing
  • Generator / transformer reverse power relays.

Specification:
Input    :    400V – 440V TPN, 50Hz
Output :    1) Reference Phase (current) – 0 - 5Amp Continuously adjustable.

                   Current extension with additional CT: 5A / 1 – 10A

2) Phase shifted voltage 0 – 120V continuously adjustable with phase
angle shift   0 to ± 180° with reference to current reference phase.
